Fast & Easy Installation: Prefabricated for quick installation, minimal building work, and low disruption. Requires minimal pit depth or can be installed directly on the floor.
Space-Saving Design: Compact design has no shaft and no pit required allowing it to fit various spaces and minimizes floor space usage.
All-Inclusive Solution: Includes all necessary components for installation, streamlining the process.
Cost-Effective: Energy-efficient operation and reduced installation time minimize overall costs.
Ideal Applications
Residential Homes
Improves accessibility for multi-story homes.
Commercial Buildings
Provides easy access for customers and employees.
Public Buildings
Ensures accessibility in government buildings and other public spaces.
Restaurants and Retail Stores
Accommodates customers with mobility limitations.
Features
Max number of stops
6 stops
Max travel height
20,000 mm
Power supply
1 phase 220V / 3 phase 220 V / 3 phase 400 V
Minimum height top floor
2250mm (1100 / 1300 optional with half gate)
Bottom pit requirements
60-70 mm / 0 mm optional with ramp
Product standard
MD 2006/42/EC, EN81-41, certified by SIL3
Drive mode
Screw-Drive
Rated power
1500 W (EcoSilent)
Machine room
None (integrated solution)
Door opening direction
Flexible choice for 3 sides
Safety device
360° catchment protection. Emergency Battery Lowering in case of power failure. Overload alarm device. Emergency communication device. Electronic and mechanical safety door protection system. Can be connected to fire alarm device.
Shaft option
Laminated glass on 5 sides or powder-coated Steel Panels
The first step toward a truly luxe experience. With a state-of-the-art touchscreen, and a beautifully simple platform, the K60 takes home lifts to a whole new level.
K60 Platform
K60 Control Panel
Touchscreen
3 Spot Lighting
Dialpad Phone
Emergency Stop Button
Premium Handrail
Silicon Safety Bar
K60 Shaft
1000 Glass Panels
AL5 Glass Maximizing Door
Technology
Screw Drive
EcoSilent
European EN81-41
K70
For the intelligent customer – the K70 comes packed with luxurious details such as PU leather finishes, extra lighting and more customization.
K70 Platform
K60 Control Panel
Touchscreen
4 Spot Lighting
Dialpad Phone
Floor Level Indicator
Light Strip
PU Leather Panel and Safety Bar
K70 Shaft
1200 mm Glass Panels
AL6 Glass Maximizing Door
Technology
Screw Drive
EcoSilent
European EN81-41
K90
The top-of-the-line Kosmos, K90 comes with features no other lift has: a built-in high-powered custom fan and LiT edges, for the ultimate lift experience.
K90 Platform
K60 Control Panel
Touchscreen
5 Spot Lighting
Dialpad Phone
LiT Safety Edge
High Power Fan
PU Leather Panel and Safety Bar
K90 Shaft
1200 mm Glass Panels
AL6 Glass Maximizing Door
Technology
Screw Drive
EcoSilent
European EN81-41
K60
K70
K90
K60
The first step toward a truly luxe experience. With a state-of-the-art touchscreen, and a beautifully simple platform, the K60 takes home lifts to a whole new level.
K60 Platform
K60 Control Panel
Touchscreen
3 Spot Lighting
Dialpad Phone
Emergency Stop Button
Premium Handrail
Silicon Safety Bar
K60 Shaft
1000 Glass Panels
AL5 Glass Maximizing Door
Technology
Screw Drive
EcoSilent
European EN81-41
K70
For the intelligent customer – the K70 comes packed with luxurious details such as PU leather finishes, extra lighting and more customization.
K70 Platform
K60 Control Panel
Touchscreen
4 Spot Lighting
Dialpad Phone
Floor Level Indicator
Light Strip
PU Leather Panel and Safety Bar
K70 Shaft
1200 mm Glass Panels
AL6 Glass Maximizing Door
Technology
Screw Drive
EcoSilent
European EN81-41
K90
The top-of-the-line Kosmos, K90 comes with features no other lift has: a built-in high-powered custom fan and LiT edges, for the ultimate lift experience.
K90 Platform
K60 Control Panel
Touchscreen
5 Spot Lighting
Dialpad Phone
LiT Safety Edge
High Power Fan
PU Leather Panel and Safety Bar
K90 Shaft
1200 mm Glass Panels
AL6 Glass Maximizing Door
Technology
Screw Drive
EcoSilent
European EN81-41
K60
K70
K90
Control Panel
Emergency Stop
Freedial Phone
Touchscreen
Silica Safety Bar
Leather Safety Bar
Floor Level Indicator
Black COP
Silver COP
PU Leather Panel
Light Strip
Built-in Fan
Spotlights
3
4
5
Shaft
1000 mm Panels
1200 mm Panels
Door
AL5 Door
AL6 Door
Reset Button
Touchscreen Call Button
Built In Level Indicator
Other
Optional Child Lock
Optional Other Locks
LiT Safety Edges
Color Options
Standard Colors
Organic Signal White AE03059900320
Oriental Oyster White AE03051101320
Oriental Grey Beige AE03051101920
Oriental Pale Brown AE03058802520
Gothic Graphite Black AE03054901120
Glacial Slate Grey AE03057701520
Ancient Oxide Red AE03053300920
Oxide 1 AE03418112320
Oxide 2 AE03418112420
Oxide 3 AE03218112520
Quartz 1 AE03411122820
Quartz 2 AE03411122920
Oxide 5 AE03218112620
January 4 AE03217049420
January 2 AE03117173520
Amethyst 2 AE03213111220
February 4 AE50107050420
February 5 AE03217050520
February 6 AE03217050620
Azurite 2 AE03217131820
Azurite 4 AE03215113920
Premium Colors
Anodic Sapphire AE20105000520
Roman Gold BAE60100009035
Roman Bronze BAE60100009235
Anodic Gold AE20111000820
Floor Options
Black Pine Selected Standard Wood
Teak
Maple
Pearwood
Guldkant - 8053H
Vävd - Eco 44010
Stjärnklar - Eco 8019H
Nattsvart - 11010BS
Ädelmetall - 8014H
Ström -Eco 8013H
Door Options
Glazing
Clear Glass
Light Fume Brown
Dark Fume Brown
Light Fume Grey
Dark Fume Grey
Polar White
Arctic Snow
Completely Modular Design for Quick Installation
Silent and Sustainable Technology
Drive Unit
The new drive unit has been completely redesigned for silent and energy-efficient operation.
Guide rollers
The guide rollers reduce the frictional force by 90% and need no lubrication, which facilitates maintenance.
Drive unit
The lifting screw has a 3 x higher pitch (36 mm) and the new screw joints are so smooth that you hardly notice them during lift travel.
Guide rollers
The drive unit is enclosed in an elegant soundproof metal casing, designed to cover up the drive unit and to eliminate highfrequency noise.
Ecosilent
Lifts equipped with the EcoSilent system are extremely quiet. Inside the lift, the sound level is 55 dB equivalent to the sound of a dish washer. Outside the lift, the sound level is 40 dB.
